Silt Fence with Welded Wire | ||||
Item Code | Roll Size | Welded Wire | Fabric | Fabric Size |
WBSF001 | 24" X100' | 14AWGX2" X4" | 70G | 36" X100' |
WBSF002 | 24" X100' | 14AWGX2" X4" | 100G | 36" X100' |
WBSF003 | 36" X100' | 14AWGX2" X4" | 100G | 48" X100' |
WBSF004 | 24" X100' | 14AWGX4" X4" | 70G | 36" X100' |
WBSF005 | 24" X100' | 14AWGX4" X4" | 100G | 36" X100' |
WBSF006 | 36" X100' | 14AWGX4" X4" | 100G | 42" X100' |
WBSF007 | 24" X100' | 12.5AWGX2" X4" | 100G | 36" X100' |
WBSF008 | 36" X100' | 12.5AWGX2" X4" | 100G | 48" X100' |
WBSF009 | 30" X100' | 12.5AWGX2" X4" | 100G | 36" X100' |
Non-Woven Silt Fence with Welded Wire | ||||
Item Code | Roll Size | Welded Wire | Fabric | Fabric Size |
WBSF001 | 24" X100' | 12.5GaugeX2" X4" | 170G | 36" X100' |
WBSF002 | 24" X100' | 14GaugeX2" X4" | 135G | 36" X100' |
WBSF003 | 24" X100' | 1.95MMX2" X4" | 210G | 36" X100' |
WBSF004 | 24" X100' | 2.4MMX2" X4" | 200G | 36" X100' |
Silt Fence with Field Wire | |||
Item Code | Field Wire | Fabric | Fabric Size |
WBSF001 | 14.5AWGX32" X110' | 70G | 3' X110' |
WBSF002 | 12.5AWGX32" X110' | 70G | 3' X110' |
WBSF003 | 14.5AWGX32" X330' | 70G | 3' X330' |
WBSF004 | 12.5AWGX32" X330' | 100G | 3' X330' |
Note: Vertical wire pitch: 12" Line Wire No.: 6pcs or 8pcs. In addition to the 32" height, there are 39" and 47" height, line wire qty will be 9pcs. Some clients would like to get the wire by BWG. | |||
Super Silt Fence |
11-1/2Gaugex42" x50' Chain Link Fence |
48" x50'/300' Black Silt Fence |
2.5" x6' Galvanized Fence Post |
Hog Rings |
Aluminium Tie Wire |
| T Post/Studded T Post/T Bar | ||||||||
| Type | Size | Height | ||||||
| Light Duty | 0.83lbs/ft | 4' | 5' | 5.5' | 6' | 7' | ||
| 0.85lbs/ft | 4' | 5' | 5.5' | 6' | 7' | |||
| 0.9lbs/ft | 4' | 5' | 5.5' | 6' | 7' | |||
| 0.95lbs/ft | 4' | 5' | 5.5' | 6' | 7' | |||
| Regular Duty | 1.10lbs/ft | 4' | 5' | 6' | 7' | 8' | 9' | 10' |
| 1.15lbs/ft | 4' | 5' | 6' | 7' | 8' | 9' | 10' | |
| 1.25lbs/ft | 4' | 5' | 6' | 7' | 8' | 9' | 10' | |
| Heavy Duty | 1.33lbs/ft | 4' | 5' | 6' | 7' | 8' | 9' | 10' |
| Safety Fence | |||||
| Type | Color | Roll Height m | Roll Length m | Hole Size mm | Weight G/m² |
| Round Rectangle | Orange, Green, Blue, Black, Yellow | 1, 1.2, 1.5, 1.8 | 15, 30, 50 | 100x40 | 80-360 |
| Round Square | Orange, Green, Blue, Black, Yellow | 1, 1.2, 1.5, 1.8 | 15, 30, 50 | 45x45 | 80-360 |
| Oval Opening | Orange, Green, Blue, Black, Yellow | 1, 1.2, 1.5, 1.8 | 15, 30, 50 | 65x35 | 80-360 |
| Oval Opening | Orange, Green, Blue, Black, Yellow | 1, 1.2, 1.5, 1.8 | 15, 30, 50 | 100x70 | 80-360 |
| Flat Oval Opening | Orange, Green, Blue, Black, Yellow | 1, 1.2, 1.5, 1.8 | 15, 30, 50 | 100x26 | 80-360 |
| Snow Fence | Orange, Green, Blue, Black, Yellow | 1, 1.2 | 15, 30, 50 | 45x45 | 160-360 |
| Diamond Grid | Orange, Green, Blue, Black, Yellow | 1.2 | 15, 30, 50 | 60x60 | 240-600 |
| Diamond Grid | Orange, Green, Blue, Black, Yellow | 1.2 | 15, 30, 50 | 38x38 | 240-600 |
| Flat Top Diamond Grid | Orange, Green, Blue, Black, Yellow | 1.2 | 15, 30, 50 | 38x38 | 240-600 |
| Welded Mesh Panel | ||
| Hole Size | Wire Diameter mm | |
| In Inch | In Millimeter | |
| 2x2 | 50x50 | 1.6, 2, 2.5 |
| 2x3 | 50x75 | 1.6, 2, 2.5 |
| 3x3 | 75x75 | 1.6, 1.8, 2, 2.5, 3 |
| 2x4 | 50x100 | 2, 3, 4, 5, 6 |
| 4x4 | 100x100 | 3, 4, 5, 6 |
| 2x8 | 50x200 | 3, 4, 5, 6 |
| 1. Standard height: 0.5-2.5m 2. Standard width: 0.5-3.0m 3. Customized size also can be acceptable | ||
| Welded Wire Mesh | |||
| Gauge | Hole Size | Height | Length |
| 22, 23, 24 | 1/4"x1/4" | 18", 24", 30", 36", 48" | 10', 25', 50', 100' |
| 19, 20, 21, 22 | 3/8"x3/8" | 18", 24", 30", 36", 48" | 10', 25', 50', 100' |
| 16, 17, 18, 19, 20, 21, 22, 23 | 1/2"x1/2" | 18", 24", 30", 36", 48" | 10', 25', 50', 100' |
| 18, 19, 20, 21, 22, 23 | 5/8"x5/8" | 18", 24", 30", 36", 48" | 10', 25', 50', 100' |
| 16, 17, 18, 19, 20, 21, 22, 23 | 3/4"x3/4" | 18", 24", 30", 36", 48" | 10', 25', 50', 100' |
| 16, 17, 18, 19, 20, 21 | 1/2"x1" | 18", 24", 30", 36", 48" | 10', 25', 50', 100' |
| 16, 17, 18, 19, 20, 21 | 1"x1" | 18", 24", 30", 36", 48", 60", 72" | 50', 100', 200', 300' |
| 14, 15, 16 | 1"x2" | 18", 24", 30", 36", 48", 60", 72" | 50', 100', 200', 300' |
| 12, 13, 14, 15, 16 | 2"x2" | 18", 24", 30", 36", 48", 60", 72" | 50', 100', 200', 300' |
| 12, 13, 14, 15, 16 | 2"x3" | 18", 24", 30", 36", 48", 60", 72" | 50', 100', 200', 300' |
| 12, 13, 14, 15, 16 | 2"x4" | 18", 24", 30", 36", 48", 60", 72" | 50', 100', 200', 300' |
| 11, 12, 13, 14, 15, 16 | 4"x4" | 18", 24", 30", 36", 48", 60", 72" | 50', 100', 200', 300' |
